Motorizations

In Ima Tecno we design and manufacture motors that can be applied directly to the RAMs of machine tools, or to drive mechanical milling heads, or for speed changes.

Download catalog

Taylor Made
  • Power 250 kW
  • Torque 5000 Nm
  • Speed 15.000 rpm



DESCH MOTOR GEARBOX UNIT Denox® HSE

Description - Data HSE 40 HSE 60 HSE 80 HSE 100
Power P kW 40 60 80  100
Speed n rpm 1500 1400 1200  955
Torque T1 Nm 250 400 650 1000
Ratio i   1/5 1/5 1/5 1/5
Nominal Torque T2 Nm 1250 2000 3250  5000
Max Speed n rpm 7000 6000  4500  4000
Outer Diameter A mm 240 260  300 350
Hollow Shaft Diameter B mm 25 30 35 36
Reducer Length C mm 430 490 550 600
Total Lenght D mm 1150 1250 1300 1400
Mounting Position     Horizontal / Vertical
Efficiency eta % 0.97





DESCH MOTOR GEARBOX UNIT Denox® HS

Description - Data HS 60 HS 80 HS 100 HS 120 HS 140
Power P kW 60

80

104 125 140
Speed n rpm 1460 1200 1700 1500 1300
Torque T1 Nm 390 650 585 800 1000
Ratio i   1,00/4,00/14,17 1,00/3,5/12,80 1,00/4,50/15,88 1,00/4,00/14,17 1,00/4,00/16,00
Nominal Torque T2 Nm 5500 8300 9300  11300 16000
Max Speed n rpm 6000 6000  5000  4500 4000
Outer Diameter A mm 260 300  350 350 400
Hollow Shaft Diameter B mm 35 45 45 45 45
Reducer Length C mm 1750 950 970 970 1000
Total Lenght D mm 1150 1800 1700 1700 2000
Mounting Position     Horizontal / Vertical
Efficiency eta % 94




Main Info for Motorizations

The adoption of these motors allows the transmission of the motion with high power and torque in milling heads and speed changes. Having extremely small dimensions, the application allows to simplify the layout of the machine in terms of overall dimensions.

  • Power 250 kW
  • Torque 5000 Nm
  • Speed 15,000 rpm
